2D Wired Barcode Scanner
BS-0615
- Easy to use, stylish appearance and strong performance.
- Unique appearance and stable structure.
- Ultra long depth of field, support scanning barcodes from a wide range.
- Quick reading all kinds of 1D/2D barcodes on paper and screen.
- Strong decoding capability on 3mil barcodes and difficult barcodes (blurred, wrinkled, low contrast, high density, long barcodes).
- Support multiple interfaces, USB HID, USB-VCOM and RS-232.
- Fit with retail stores, supermarkets, restaurants, pharmacies, etc.
- Code: SX-BS-0615.
- CPU: 32bits ARM.
- Light source: White LED (lighting) Red LED (aiming).
- Scan mode: Manual, automatic, continuous.
- Image sensor: CMOS.
- Resolution: 640×480 pixels.
- Scan speed: 60fps.
- Scan precision: ≥3mil (code 128 6 digits).
- Depth of field: 60~300mm (13mil code39).
- Print contrast: ≥15%.
- Interface: USB-HID, USB-VCP, RS232.
- Decoding capability 1D: Codabar, Code11, Code39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code93, Code128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, ISBN, ISSN, GS1 DataBar (RSS14), GS1 DataBar Limited, GS1 DataBar Expanded, MSI, Standard 25, Plessey / 2D: PDF417, Micro PDF417, QR Code, Data Matrix, Aztec Code, Hanxin code, Maxicode.
- Size: L×W×H: 170.9×64.4×86.8 (mm).
- Weight: 175g (scanner); 175g (base).
- Case material: ABS+PC.
- Input voltage: DC5V±5%.
- Working current: 180mA.
- Standby current: 75mA.
- Temperature (operating): -10˚C~50˚C.
- Temperature (storage): -20˚C~60˚C.
- Humidity: 5% to 95% (non-condensing).
- IP grade: IP42 (1.5m drop).
- Ambient light resistance: 0-100000 lux.
- Size L×W×H: 170.9×64.4×86.8 (mm).
- Weight: 175g (scanner); 175g (base).
